heavy Duty Wheel Repair Lathe CK6197W is high precision, cost-effective and space-saving. These car CNC wheel lathes are your best choice for wheel machining, super-finishing, and maintenance. Alloy wheel CNC Machine CK6197W is widely used for wheel machining, super-finishing, and maintenance. These Diamond Cut Alloy CNC Machine has the characteristics of high quality, high precision, and high efficiency and are composed of self-made mechanical parts such as the cast bed, spindle, fixing chuck and the feeding mechanism, the imported numerical control system， the automatic measuring system, the famous brand servo motors and the auxiliary parts like lubrication, light, and cooling.
Our customer has a very large car repair company in India, and they wanted to purchase a heavy and reliable wheel lathe as a trial order. After confirming the maximum wheel size, the customer stated that he needed the largest lathe so that there would be larger wheels in the future. And they carefully compared all the machines and configurations and found that Heavy Duty Wheel Repair Lathe CK6197W is more suitable.
We provided detailed information on wheel CNC lathe CK6197W, as well as common configuration and operation videos. The customer was quite satisfied and has done detailed research on the parts of the CNC wheel lathe. Finally, they decided to buy a wheel repair lathe CK6197W.
After the Heavy Duty Wheel Repair Lathe CK6197W, they told us he very much trusts us and no need to come to check. So we sent them the Alloy wheel repair lathe operate video and detailed pictures. They were was very satisfied with our wheel CNC lathe.
Heavy Duty Wheel Repair Lathe CK6197W Specifications
| Project name | Unit | Technical parameters |
| Machining wheel diameter | Inch | 35” |
| Max. workpiece length | mm | 750 |
| Probe measuring direction | X、Z | |
| Detection type | Laser | |
| Machining accuracy | IT6~IT7 | |
| Surface roughness | um | Ra0.8~1.6 |
| Main transmission form | Independent spindle; stepless frequency conversion | |
| Range of spindle speed | rpm | 150~2000 |
| Main motor power | kw | 11 |
| Fast-moving feed | mm/min | X – axis:5000 Z – axis:8000 |
| Repeat positioning accuracy | mm | X – axis:0.01 Z – axis:0.015 |
| Standard accessories | 4 station electric tool | |
| Repeat positioning accuracy(mm) | mm | 0.008 |
| Section of turning tool(mm) | mm | 25×25 |
Main Features of Heavy Duty Wheel Repair Lathe CK6197W
- Wheel repair special CNC lathe. The new design, new structure, new technology.
- Achieve the wheel surface profile measurement and data collection and Program Optimization.
- Automatic precision repair and machining in accordance with the curve of the wheel surface.
- Self-developed curve optimization software. Multilingual language interface. Installation and operation are simple.
- Spindle frequency step-less speed.
- X / Z-axis servo drive.
- Manual jaw self-centering chuck.
- Machine guard full protection.
- Security and fault alarm indication.
- Automatic oil lubrication.
- Diamond turning, to achieve high-precision smooth machining on the wheel surface.
- Wheel Repair CNC Lathe Applications
- The wheel CNC machine tool is suitable for High-precision turning and repair processing for the surface of the car wheel.
- The wheel repair lathe has also the function of the general CNC lathes.
