Vertical Wheel Surface Repair Machine CKL-35 is the ideal wheel lathe for wheel repair. The wheel CNC lathe is newly designed and manufactured by HAISHU Machinery, and has strong professionalism, complete functions, good performance and easy operation specific CNC machine to repair and maintain alloy car wheels. The vertical wheel repair lathes has a cast steel frame with good looks and is rounded off with our HAISHU CNC software, uses a liquid crystal touch screen operation. This wheel lathe makes up for the universal system’s shortcomings for the wheel repair, professional is strong, full functions, good performance, easy to operate, automatic and easy to use with technical support and training. It can process wheels and store profiles on the system to build up your very own wheel profile library, so it can save you time! Vertical wheel repair lathe product quality is reliable, high configuration, low price.
This Sweden customer has a 4s shop for a luxury car and now he needed a Wheel Surface Repair Machine. He requested a Vertical Wheel Surface Repair Machine can process big rim. So we chose the wheel CNC lathe CKL-35 for him which can process max wheel size up to 35 inches. He also requested that the Rim Turning Lathe realized automatic and operate easily. We sent him Vertical wheel Turning Lathe CKL-35 detail and operate videos. He was very satisfied and confirmed the configuration and voltage. We provide a detail quotation of the Wheel Surface Repair Machine. He was also very happy and said our Vertical wheel CNC Lathe was exactly what he needed, Then he requested the PI immediately.
A few days later, The Vertical Wheel Surface Repair Machine CKL-35 was completed, he told us not have time to come to check. So we sent him the wheel CNC Machine operate the video. He was very satisfied and expressed that he will need more sets soon.
Vertical Wheel Surface Repair Machine CKL-35 Specifications
| Item | Unit | Specifications |
|---|---|---|
| Model | Vertical Wheel Repair Lathe CKL-35 | |
| Max. turning diameter | mm | 1000 |
| Max. machining wheel diameter | mm | 900 |
| Chuck maximum clamping diameter | mm | 920 |
| Spindle speed (frequency | rpm | 50-1200 |
| Turret vertical movement distance | mm | 450 |
| X axis fast moving speed | mm/min | 1500 |
| Z axis fast moving speed | mm/min | 8000 |
| Turret form | mm | 25×25 |
| Main motor power | KW | 5.5 |
| Machine Weight | KG | 1500 |
| Machine Size | mm | 2000*1500*2000 |
Vertical Wheel Surface Repair Machine CKL-35 Features
- Newly developed Vertical Rim Turning Lathe CKL-35 by HAISHU Machinery for alloy car wheel repair and superfinishing.
- Cast iron bed. The wheel repair CNC lathe bed is made of cast steel in a vertical structure.
- Large wheel processing diameter. The max wheel processing diameter is up to 35 “.
- Self-developed special wheel repair control software. Automatic wheel surface measurement and program optimization can be realized simultaneously.
- Laser non-contact measurement or probe contact measurement are optional. Laser measurement enables fast scanning.
- Teaching function. The overall wheel surface can be repaired, but also can be partially repaired.
- LCD touch screen configuration
- Compared with the horizontal structure, the mechanical transmission is more stable, the turning performance is better and the machining precision is higher.
- Small machine tool space, professional Vertical Rim Turning Lathe for wheel repair.
- Professional after-sale service including software free upgrade and remote operation and technical training on the wheel CNC machine’s LCD display.
- High performance, cost-effective.
- Easy to operate and maintain.
Wheel Repair Lathe CKL-35 Configurations
- CNC system: “HAISHU” LCD touch screen CNC system
- Laser probe
- Precision spindle unit
- Z-axis dual servo motor drive
- X, Z axis linear guide
- Precision screw vice
- Software and hardware limit
- Rail protection system
- Automatic lubrication system
- Air cooling system
- Air gun
- MPG
- Warning lights
- Full protection outer casing
- Chip removal box
- Pneumatic door
- Long jaw chuck
- 2 Station row turret
- Z safety brake
Vertical Wheel Surface Repair Machine CKL-35 Applications
Rim Turning Lathe CKL-35 is the best wheel CNC machine to repair and process the alloy car wheel surface, center hole and rim, etc.
